Blackeel™ Nitinol hydrophilic guidewire with soft and atraumatic tip and Tungsten blended polymer to provide superior elasticity, kink resistance, torque control and high visibility. Durable hydrophilic coating of the wire ensures lubricity to pass through the tortuous vessels.
- Elastic material and integrated design allow 1:1 torque response to deliver the guidewire into the target vessel quickly.
- Tungsten blended polymer ensures enhanced visibility under X-ray and enables accurate positioning.
- Patented hydrophilic coating o ers a durable and smooth approach possible even in tortuous vessels.
- Tapered design ensures a soft and atraumatic tip to cross tortuous anatomy.
| Curve | Length | 0.018"/Standard | 0.025"/Standard | 0.032"/Standard | 0.035"/Standard | 0.038"/Standard |
|---|---|---|---|---|---|---|
| A | 120cm | 10A11812 | 10A12512 | 10A13212 | 10A13512 | 10A13812 |
| 150cm | 10A11815 | 10A12515 | 10A13215 | 10A13515 | 10A13815 | |
| 180cm | 10A11818 | 10A12518 | 10A13218 | 10A13518 | 10A13818 | |
| 260cm | 10A11826 | 10A12526 | 10A13226 | 10A13526 | 10A13826 | |
| S | 120cm | 10S11812 | 10S12512 | 10S13212 | 10S13512 | 10S13812 |
| 150cm | 10S11815 | 10S12515 | 10S13215 | 10S13515 | 10S13815 | |
| 180cm | 10S11818 | 10S12518 | 10S13218 | 10S13518 | 10S13818 | |
| 260cm | 10S11826 | 10S12526 | 10S13226 | 10S13526 | 10S13826 | |
| R1.5mmJ | 120cm | 10J31812 | 10J32512 | 10J33212 | 10J33512 | 10J33812 |
| 150cm | 10J31815 | 10J32515 | 10J33215 | 10J33515 | 10J33815 | |
| 180cm | 10J31818 | 10J32518 | 10J33218 | 10J33518 | 10J33818 | |
| 260cm | 10J31826 | 10J32526 | 10J33226 | 10J33526 | 10J33826 | |
| R3mmJ | 120cm | 10J51812 | 10J52512 | 10J53212 | 10J53512 | 10J53812 |
| 150cm | 10J51815 | 10J52515 | 10J53215 | 10J53515 | 10J53815 | |
| 180cm | 10J51818 | 10J52518 | 10J53218 | 10J53518 | 10J53818 | |
| 260cm | 10J51826 | 10J52526 | 10J53226 | 10J53526 | 10J53826 |
| Curve | Length | 0.018"/Stiff | 0.025"/Stiff | 0.032"/Stiff | 0.035"/Stiff | 0.038"/Stiff |
|---|---|---|---|---|---|---|
| A | 150cm | - | 10A22515 | 10A23215 | 10A23515 | 10A23815 |
| 180cm | - | 10A22518 | 10A23218 | 10A23518 | 10A23818 | |
| 260cm | - | - | - | 10A23526 | 10A23826 | |
| S | 150cm | - | - | - | 10S23515 | 10S23815 |
| 180cm | - | - | - | 10S23518 | 10S23818 | |
| 260cm | - | - | - | 10S23526 | 10S23826 |
